Page #48 background imageLoading...
Page #48 background image
48
6915L-0284B
WRL LED,Top View,2ea(LED Chip Q'TY per
PKG), 7020PKG,
6920L-0084A
299.5*4.2*1.2, 2ea(Number Of Chain),
1L(Number Of Layer), 36ea(Number Of LED),
AL
7250L-1482A TP-15,(0.25T), 298.6*3.6*0.25
7250L-0864A NITTO, NITTO 5000NS, Clear, 30*3*0.16
7250L-1408A ZH350 25x16x0.1
7250L-1488B
Conductive Tape,
STN1026W(P),15*25,T=0.11
756GFBCB-AA005--00 MCU ASS'Y
U402 056G2233501
IC FLASH MX25L2026DM1I-12G 2Mb SOP-8
MXIC
SMTCA-U402 100GANJD001FT1 AOC E2351 VH
A15G1636301 Main-frame
A15G1648101 PlATE
A33G1203AED-1B0100 stand-top
A33G1204--1-1C0100 Power lens
A34G2581AED-1B0100 Stand-cover
A34G2597AEDB1B0130 BEZEL
A34G2598AED-2B0100 rear cover
A34G2618AED-1B0130 BASE
A37G0252011 HINGE
ADPCA1236YA2 ADAPTER BOARD
CBPCANZA1A1 COVERSION BOARD
CN406 033G801930F-CH--JS WAFER 30P 1.0MM JINGSHI
C716 067G204V471-2L CS CAP 470uF
067G204V471-2K CS CAP 470uF 10V 8*8 mm 2nd source
C807 067G415R479-9L EC 4.7UF 20% 100V RZW 8*12
067G415R479-9K EC 4.7UF 20% 100V ED 8*12 2nd source
FB701 071G--5526A--H CORE 6.0X3.5X3.5 127 25% 3.5X6.0
071G--5526A--S CORE 6.0X3.5X3.5 127 25% 2nd source
CN101 088G-35315FVCL
D-SUB CONN WITH SCREW 15P BLUE
CL
088G-35315FVXH
D-SUB CONN WITH SCREW 15P BLUE
XIANHE
2nd source
CN102 088G354GOF1VXH
DVI CONN WITH SCREW 24P WHITE
XIANHE
088G-35424F-VC DVI CONN WITH SCREW 24P WHITE CL 2nd source
X401 093G--2251B--J CRYSTAL 12MHZ NXS12.000AC30F-KAB10
CN405 311GF100A06AAJ FFC CONN 6P 1.0MM JINGSHI
