AOC e2360Pda User Manual

24
4.3.3 Electrical Characteristics
Parameter Symbol
Values
Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage V
LCD
4.5 5.0 5.5 Vdc
Permissive Power Input Ripple V
LCD
- - 0.3 V 3
Power Supply Input Current
I
LCD-MOSAIC
(60Hz) - 1200 1560 mA 1,5
I
LCD-BLACK
(60Hz) - 1400 1820 mA 2,5
I
LCD-BLACK
(75Hz) - 2260 mA 5
Power Consumption P
LCD
- 6.0 7.8 Watt 1
Inrush current I
RUSH
- - 3.5 A 1, 4
LED bar Electrical characteristics
Parameter Symbol Condition
Values
Unit Notes
Min. Typ. Max.
LED : 1,7
LED String Current Is - 120 125 mA 2,7
LED String Voltage Vs 54.0 57.6 61.2 V 3,7
Power Consumption PBar - 13.8 14.7 Watt 4,6,7
LED Life Time LED_LT 30,000 - - Hrs 5,7
