59
No. Description
1 BEZEL L27WA-U52
2 KEY
3 LENS
4 MAIN_FRAME
5 HINGE_27"
6 REAR COVER 27"
7 STAND
8 BASE L27WA-S1
No. Part No. Description
9 FOOT S1 0D1G1040 8120 SCREW(POWER BOARD)
10 SHIELD USB S2 0D1G1030 8120 SCREW(POWER BOARD/MAIN_FRAME)
11 USB BOARD S3 0D1G1030 6120 SCREW(MAIN BOARD/MAIN_FRAME)
12 MAIN BOARD S4 0Q1G 930 8120 SCREW(SHIELD USB/REAR COVER)
13 POWER BOARD S5 AM1G1740 10225 CR3 SCREW(HINGE/STAND)
14 PANEL S6 AM1G1740 10225 CR3 SCREW(HINGE/REAR COVER)
15 KEY BOARD S7 0M1G 930 6 47 CR3 SCREW(HDMI)
16 SPEAKER S8 0M1G 930 8 47 CR3 SCREW(REAR COVER/ MAIN_FRAME)
