AOC E960SWDA Service Manual

59
088G-35315F-HD D-SUB CONN WITH SCREW 15P BLUE DLK
2nd
SOURCE
CN102 088G-35424FXNH
DVI CONN WITH SCREW 24P WHITE
XIANHE
X401 093G--22-53CEC
DIODE CRY 14.31818MHZ
S-F-14.31818M-32-3030-2085-30 CEC
093G--22-53--J Diode CRY 14.31818MHZ/32PF/49US NSK
2nd
SOURCE
H40G-45762429A CBCP Label for EE
U401 056G-562A23 IC SCALER TSUMU58VHN LQFP-80 MSTAR
U701 056G-563527BHF IC LDO BL1117-33CX 1A 3.3V SOT-223 Belling
056G-585-4A IC LDO AP1117E33G-13 1A 3.3V SOT223 Diodes
2nd
SOURCE
U101,U103,U104,U10
6,U107
056G-662-52
IC ESD PROTECT AZC398-04S.R7G SOT23-6
Amazing
056G-662-48
IC ESD PROTECT AZC399-04S SOT23-6L
AMAZING
2nd
SOURCE
U102,U105 056G1133-34--1 IC EEPROM M24C02-RMN6TP 2Kb SO-8 ST
056G1133158
IC EEPROM CAT24C02WI-GT3A 2Kb SOIC-8
ON
2nd
SOURCE
U402 056G2233-11 IC FLASH Pm25LD020C-SCE SIOC-8 2M PMC
Q401,Q403 057G-417517 TRA LMBT3906LT1G -0.2A/-40V SOT-23 LRC
057G-417512
TRA MMBT3906 0.2A/40V SOT-23 BLUE
ROCKET
2nd
SOURCE
Q701,Q706 057G-417518 TRA LMBT3904LT1G 0.2A/40V SOT-23 LRC
057G-417511
TRA MMBT3904 0.2A/40V SOT-23 BLUE
ROCKET
2nd
SOURCE
Q704 057G-763--3 MOSFET AO4411 8A/30V SO-8 AOS
R407,R409,R416,R43
2,R441
061G0402000-JY RST CHIPR 0 OHM +-5% 1/16W YAGEO
061G0402000-JT RST CHIPR MAX0R05 1/16W TZAI YUAN
2nd
SOURCE
R105,R112,R120,R13
7,R138,R139,R140,R1
41,R142,R143,R144
061G0402100-JY RST CHIPR 10 OHM +-5% 1/16W 0402 YAGEO
061G0402100-JT
RST CHIPR 10 OHM -5% 1/16W 0402 TZAI
YUAN
2nd
SOURCE
R419,R420 061G0402101-JT
RST CHIPR 100 OHM +-5% 1/16W 0402 TZAI
YUAN
061G0402101-JY RST CHIPR 100 OHM -5% 1/16W 0402 YAGEO
2nd
SOURCE
