AOC E960SWDA Service Manual

67
SOURCE
709G4033-QM001 COMSUPTIVE ASS'Y
CN802 311GF050B10ADL FFC CONN 10P 0.5MM XIANGLONG
033G801910Y--H NO-SUGGEST WAFER 10P 0.5MM GAOLIN
2nd
SOURCE
311GF050B10ADH FFC CONN 10P 0.5MM HR
2nd
SOURCE
709G4033-QS001 COMSUPTIVE ASS'Y
E715 715G4033P01000004I Power board FR-4 DS 20*20*1.6mm 42
715G4033P01000004
L
Power board FR-4 DS 20*20*1.6mm 42
2nd
SOURCE
715G4033P01000004
S
Power board FR-4 DS 20*20*1.6mm 42
2nd
SOURCE
U901 056G-379529
IC AC/DC CONVERTER LD7576AGR SOP-7
LEADTREND
U801 056G-700-11
IC LED DRIVER OZ9998BGN-A1-0-TR SOP-16
O2
Q801 057G-763947
MOSFET APM8005KCTRG 5.2A/80V SOP-8
ANPEC
057G-763-92 MOSFET P8008HV 4A/80V SOP-8 NIKO-SEM
2nd
SOURCE
R610 061G0603000-JF RST CHIPR MAX 0R05 1/10W FENGHUA
061G0603000-JT RST CHIP MAX 0R05 1/10W TZAI YUAN
2nd
SOURCE
R612 061G0603103-JI RST CHIPR 10 KOHM +-5% 1/10W 0603 TA-I
061G0603103-JT
RST CHIPR 10 KOHM -5% 1/10W 0603 TZAI
YUAN
2nd
SOURCE
R603,R609 061G0603103-JT
RST CHIPR 10 KOHM +-5% 1/10W 0603 TZAI
YUAN
061G0603103-JF
RST CHIPR 10 KOHM -5% 1/10W 0603
FENGHUA
2nd
SOURCE
061G0603103-JY RST CHIPR 10 KOHM -5% 1/10W 0603 YAGEO
2nd
SOURCE
R606,R607 061G0603562-JT
RST CHIPR 5.6 KOHM +-5% 1/10W 0603 TZAI
YUAN
061G0603562-JF
RST CHIPR 5.6 KOHM -5% 1/10W 0603
FENGHUA
2nd
SOURCE
R604,R605 061G06038201FF RST CHIPR 8.2KOHM +-1% 1/10W FENGHUA
061G06038201FI RST 0603 8.2K 1% 1/10W
2nd
SOURCE
R608,R811,R821,RJ80 061G0805000-JT RST CHIPR 0 OHM +- 5% 1/8W TZAI YUAN
