AOC E960SWDA Service Manual

73
R915 061G-17222052T--TZ RST CFR 22 OHM +-5% 1/4W TZAI YUAN
061G-17222052T--XZ RST CFR 22 OHM -5% 1/4W XIANZHENG
2nd
SOURCE
R906
061G152M10452T--S
Y
MOFR 100KOHM +-5% 2WS SHUANGYU
061G152M10452T--H
X
MOFR 100KOHM -5% 2WS HUAXING
2nd
SOURCE
R924
061G152M47852T--S
Y
MOFR 0.47 OHM +-5% 2WS
061G152M47852T--H
X
MOFR 0.47 OHM -5% 2WS HUAXING
2nd
SOURCE
R904,R922
061G152M68152T--S
Y
RST MOF 680R 5% 2WS
061G152M68152T--H
X
MOFR 680 OHM -5% 2WS HUAXING
2nd
SOURCE
C816 065G--1K102-2T6921 CAP CER 1nF +-10% 1KV Y5P WANSHENG
065G--1K102-2T6213 CAP CER 1nF -10% 1KV Y5P TDK
2nd
SOURCE
C911 065G--2K152-2T6921 CAP CER 1500pF K 2KV Y5P
065G--2K152-2T6213 CAP CER 1500PF K 2KV
2nd
SOURCE
C920 067G-2041022LT EC 1000uF 20% 10V 10*12 2000Hr LELON
067G-2041022KT EC 1000uF 20% 10V 10*12 2000Hr CHINSAN
2nd
SOURCE
C809 067G-4153309LT EC 33uF +-20% 100V 8*11.5 4000H LELON
067G-4153309KT EC 33uF -20% 100V 8*12 4000H ELITE
2nd
SOURCE
C913 067G215Y4707KT 47uF 50V
067G215Y4707LT LOW ESR EC 47uF 50V M 6.3*11mm
2nd
SOURCE
FB801,FB803,FB901,F
B902
071G--55-29 FERRITE BEAD
071G--55-29--X
BEAD 3.5*2.2*0.8 45R -25% 3BDR3522-453A
ASET
2nd
SOURCE
F901,F902,F903 084G--56--4--B FUSE 4A 250V
084G--56-4W FUSE 4.0A 250V
2nd
SOURCE
ZD901 093G--3960252T
DIODE ZENER MTZJ20B 18.63-19.59V 0.5W
DO-34 Semtech
D903,D904 093G--6026T52T DIODE RECTIFIER FR107 AO 1A/1000V TSC
093G110050152T DIODE PR1007 1A/1000V 500ns DO-41 LITEON 2nd
