16
5. Block Diagram
5.1 Main Board
Scalar IC HX6822-A
(Include MCU, ADC, OSD)
(U401)
D-SUB
Connector
(CN101)
EEPROM
MX25L2026DM1I-12G
(U402)
D-HS
D-VS
RGB
LCD Interface
(CN410)
Key Control
interface
(CN406)
Crystal
12MHz
(X401)
EEROM
FM24C02A
(U101)
DDC1-SCL
DDC1-SDA
DVI
Connector
(CN102)
EEROM
FM24C02A
(U104)
DDC2-SDA
DDC2-SCL
