AOC Envision H2276WDL User Manual

43
CN410 033G801930F CH JS FFC CONN 1.0mm 30P R/A 34mm 6.3mm
CN101 088G 35315F HC D-SUB CONN 15P WITH SCREW 2nd source
CN101 088G 35315F HD D-SUB CONN 15P BLUE - R/A
CN102 088G 35424F C DVI 24PIN CONN F attached Screw
CN102 088G 35424F D DVI CONN SCREWED 24P R/A
X401 093G 2258B J CRYSTAL 24.576MHz 20PF 49US
C706 067G 3051013PB EC 105C 100uF M 16V 5*11mm JH CD263
C708 067G 3051013PB EC 105C 100uF M 16V 5*11mm JH CD263
C709 067G 3051013PB EC 105C 100uF M 16V 5*11mm JH CD263
C445 067G 3051013PB EC 105C 100uF M 16V 5*11mm JH CD263
C701 067G 3051013PB EC 105C 100uF M 16V 5*11mm JH CD263
U401 056G 562A30 SCALER HX6822-A080LAG LQFP-100
U702 056G 563 52 LDO AP1117D33G-13
U702 056G 563528BHF LDO 15V 10C/W 1.5V BL1117-33CY 1A
U105 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L
U106 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L
U107 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L
U102 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L
U103 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L
U101 056G1133 34 1 EEPROM M24C02-RMN6TP 2Kb SO-8
U104 056G1133 34 1 EEPROM M24C02-RMN6TP 2Kb SO-8
U402 056G2233501 FLASH MX25L2026DM1I-12G 2Mb SOP-8
Q701 057G 417511 MMBT3904
Q703 057G 417511 MMBT3904
Q401 057G 417512 MMBT3906
Q402 057G 417512 MMBT3906
Q401 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q402 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q701 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q703 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q704 057G 417519 TRA MMBT2907A
Q707 057G 417519 TRA MMBT2907A
Q704 057G 417527 SMALLTRAN MMBT2907A -0.6 -60V SOT-23
Q707 057G 417527 SMALLTRAN MMBT2907A -0.6 -60V SOT-23
Q706 057G 763940 MOSFET AO3401A SOT-23
R417 061G0402000 JI RST 0402 0.05R MAX 1/16W
R418 061G0402000 JI RST 0402 0.05R MAX 1/16W
R423 061G0402000 JI RST 0402 0.05R MAX 1/16W
R432 061G0402000 JI RST 0402 0.05R MAX 1/16W
R432 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN
R423 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN
R418 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN
R417 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN
R103 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
R107 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
R112 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
R127 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
R128 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
R129 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
R130 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
R113 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
R108 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
R104 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
R134 061G0402100 JI TEST ONLY RST 0402 10R 5% 1/16W TA-I
