AOC Envision H2276WDL User Manual

49
ZD103 093G 39GA01 T RLZ5.6B
ZD104 093G 39GA01 T RLZ5.6B
ZD101 093G 39S 24 T RLZ 5.6B LLDS
ZD102 093G 39S 24 T RLZ 5.6B LLDS
ZD103 093G 39S 24 T RLZ 5.6B LLDS
ZD104 093G 39S 24 T RLZ 5.6B LLDS
E715 715G5306M01000004L MAIN PCB FR4 DS 80*72*1.6MM
KEPCBQM5 KEY BOARD
CN001 095G820H 6D902 HARNESS 6P(SANW)-7P 160mm
CN001 095G820H 6W902 HARNESS 6P(SANW)-7P 160mm 2nd source
LED01 381G00122YB0GP LED yellow/Blue gp34032m/g307-zsy-50
R005 061G06032001FF RST CHIP 2KOHM 1% 1/10W FENGHUA
R002 061G06032001FF RST CHIP 2KOHM 1% 1/10W FENGHUA
R005 061G06032001FI TEST ONLY RST 0603 2K 1% 1/10W TA-I
R002 061G06032001FI TEST ONLY RST 0603 2K 1% 1/10W TA-I
R004 061G06033001FF RST CHIPR 3KOHM +-1% 1/10W FENGHUA
R003 061G06033001FF RST CHIPR 3KOHM +-1% 1/10W FENGHUA
R004 061G06033001FI TEST ONLY RST 0603 3K 1% 1/10W TA-I
R003 061G06033001FI TEST ONLY RST 0603 3K 1% 1/10W TA-I
ZD003 093G 39GA01 T RLZ5.6B
ZD007 093G 39GA01 T RLZ5.6B
ZD004 093G 39GA01 T RLZ5.6B
ZD006 093G 39GA01 T RLZ5.6B
ZD002 093G 39GA01 T RLZ5.6B
ZD001 093G 39GA01 T RLZ5.6B
ZD005 093G 39GA01 T RLZ5.6B
SW001 077G603S AI CJ TACT SWITCH AI 2PIN SEALED
SW004 077G603S AI CJ TACT SWITCH AI 2PIN SEALED
SW002 077G603S AI CJ TACT SWITCH AI 2PIN SEALED
SW005 077G603S AI CJ TACT SWITCH AI 2PIN SEALED
SW003 077G603S AI CJ TACT SWITCH AI 2PIN SEALED
SW003 077G603S AI HJ TACT SWITCH AI 2PIN SEALED
SW005 077G603S AI HJ TACT SWITCH AI 2PIN SEALED
SW004 077G603S AI HJ TACT SWITCH AI 2PIN SEALED
SW002 077G603S AI HJ TACT SWITCH AI 2PIN SEALED
SW001 077G603S AI HJ TACT SWITCH AI 2PIN SEALED
E715 715G4407K02000001S KEY PCB FR1 SS 14*130*1.6mm
PLPC1B501UAC2 POWER BOARD
H40G 45762429A LABEL
GND3 009G6005 1 GND TERMINAL
GND2 009G6005 1 GND TERMINAL
GND1 009G6005 1 GND TERMINAL
IC902 056G 139 9 IC EL817M(X) photocoupler DIP-4
IC901 056G 379205 AC/DC LD7904JGP7 DIP-6
NR901 061G 58809MEN RST NTCR 8OHM +/20%/NMM01 4A XIANZHENG
C904 063G107K224 UM X2 CAP 0.22uF K 275VAC
C809 067G 415479 9K EC 4.7UF 20% 100V ED 8*12
C809 067G 415479 9L EC 4.7UF 20% 100V 8*12
C907 067G 43Z68015L EC 68uF M 450V RGT 18*31.5mm
C909 067G204V102 2C CAP CS 1000UF 20% 10V 10*12.2
C909 067G204V102 2K CAP CS 1000UF 20% 10V 10*12
C912 067G215D6814KV EC 680UF 20% 25V ED1E681MCM1020F4P 10*20
L901 073G 174 65 H2 LINE FILTER 30mH MIN
L903 073G 253 91 F CHOKE COIL 3.5UH 10% ,HF
