AOC I2369Vm User Manual

I2769V
Panel
Model name I2769V
Driving system TFT Color LCD
Viewable Image Size
686mm Diagonal
Pixel pitch
Video R, G, B Analog lnterface ,DVI
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 170MHz
Resolution
Horizontal scan range 30kHz to 83kHz
Horizontal scan Size(Maximum) 597.888mm
Vertical scan range 50Hz to 76Hz
336.312mm
Vertical scan Size(Maximum)
Optimal preset resolution 1920×1080@60Hz
Plug & Play VESA DDC2B/C1
Input Connector VGA,DVI
Input Video Signal Analog: 0.7Vp-p(standard),75 OHM,Positive,DVI
Power Source 100-240V~, 50/60Hz
Power Consumption
Active<30W(Typical)
Standby < 0.5 W
Off timer 0-24 hrs
Physical
Characteristics
Connector Type VGA, DVI
Signal Cable Type Detachable
Dimensions & Weight:
Height (with base)
448.8mm
Width
621.9mm
Depth
213.2mm
Weight (monitor only)
4.90kg
0.1038*RGB(H)mm x 0.3114 (V)mm
Environmental Temperature:
Operating 0° to 40°
Non-Operating -25°to 55°
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 93% (non-condensing)
A
ltitude:
Operating
Non-Operating 0~ 12192m (0~ 40000 ft )
0~ 000m (0~ 6 ft )5 1 404

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
