AOC I2369Vm User Manual

AOC I2369Vm
71 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #8 background image
Setup
Contents in Box
check with the local dealer or AOC branch office for confirmation.
Monitor
Power Cable
HDMI Cable
*
Not all signal cables (VGA, DVI,MHL
and HDMI cables) will be provided for all countries and regions. Please
CD Manual
Base
Analog Cable
*
MHL Cable
*
Audio Cable
*
CableDVI
*
*
DP
Cable

Other manuals for AOC I2369Vm

Question and Answer IconNeed help?

Do you have a question about the AOC I2369Vm and is the answer not in the manual?

AOC I2369Vm Specifications

General IconGeneral
3DNo
Pixel pitch0.265 x 0.265 mm
Aspect ratio16:9
Screen shapeFlat
Backlight typeW-LED
Display surface-
Pixel frequency170 MHz
Display diagonal23 \
Display technologyLED
Vertical scan range50 - 76 Hz
Maximum refresh rate60 Hz
Horizontal scan range30 - 83 kHz
Viewable size, vertical286.74 mm
Contrast ratio (dynamic)20000000:1
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Viewable size, horizontal509.76 mm
Display brightness (typical)250 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
HDCPYes
HDMI version1.4
DisplayPort version1.1
Headphone connectivity3.5 mm
Tilt angle range-3 - 21 °
Cable lock slot typeKensington
Number of OSD languages16
Panel mounting interface75 x 75 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Annual energy consumption29 kWh
Power consumption (standby)0.5 W
Power consumption (typical)25 W
Mean time between failures (MTBF)50000 h
Feet colorBlack/Silver
CertificationGOST
Product colorBlack, Silver
Front bezel colorSilver
Heavy metals freeHg (mercury), Pb (lead)
Market positioningHome
Cables includedAC, HDMI, VGA
HDMI cable length1.5 m
Power cable length1.2 m
Package typeBox
Package depth138 mm
Package width603 mm
Package height467 mm
Package weight5480 g
Sustainability certificatesRoHS, ENERGY STAR
Operating altitude0 - 5000 m
Non-operating altitude0 - 12192 m
Storage temperature (T-T)-25 - 55 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 93 %
Operating relative humidity (H-H)10 - 85 %
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)204 mm
Height (with stand)398 mm
Weight (with stand)3760 g
Depth (without stand)44.9 mm
Width (without stand)531.4 mm
Height (without stand)326.5 mm
Weight (without stand)- g
