AOC I2475PXQU User Manual

19
Hotkeys
1
Source/Auto/Exit
2
Clear Vision/<
3
Volume/>
4
Menu/Enter
5
Power
Menu/Enter
Press to display the OSD or confirm the selection.
Power
Press the Power button to turn on/off the monitor.
Volume/>
When there is no OSD, press Volume adjust volume.
4:3 or wide image ratio / >
When there is no OSD, press hotkey continuously to change 4:3 or wide image ratio. (If the product screen size is
4:3 or input signal resolution is wide format, the hot key is disable to adjust. ).
Auto / Exit / Source hot key
When there is no OSD, press Auto/Source button continuously about 2 second to do auto configure. When the
OSD is closed, press Source button will be Source hot key function. Press Source button continuously to select the
input source showed in the message bar, press Menu/Enter button to change to the source selected.
Clear Vision
1. When there is no OSD, Press the “<” button to activate Clear Vision.
2. Use the “<” or “>” buttons to select between weak, medium, strong, or off settings. Default setting is always
“off”.

AOC I2475PXQU Specifications

General

3D	No
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Pixel frequency	170 MHz
Display diagonal	23.8 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	296.46 mm
Contrast ratio (dynamic)	200000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
Active display area (W x H)	527.04 x 296.46 mm
Mean time between failures (MTBF)	50000 h
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.1
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	4
Certification	ISO
Product color	Black
Market positioning	Business
Pivot angle	- °
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Number of OSD languages	18
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
RMS rated power	2 W
Number of speakers	2
Thin client installed	-
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (standby)	0.3 W
Power consumption (typical)	14.8 W
Package depth	420 mm
Package width	693 mm
Package height	184 mm
Package weight	7700 g
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	489 mm
Width (with stand)	554.44 mm
Height (with stand)	212.91 mm
Weight (with stand)	5530 g
Depth (without stand)	57.1 mm
Width (without stand)	554.4 mm
Height (without stand)	340 mm
Weight (without stand)	- g
