OSD Setting

Basic and simple instruction on the control keys.

1. Press the MENU-button to activate the OSD window.

2. Press or to navigate through the functions. Once the desired function is highlighted,

press the MENU-button to activate it. If there is a sub-menu, press or to navigate through the

sub-menu functions.

3. Press or to change the settings of the selected function. Press AUTO to exit. If you want to

adjust any other function, repeat steps 2-3.

4. OSD Lock Function: To lock the OSD, press and hold the MENU-button while the monitor is off and then

press power button to turn the monitor on. To un-lock the OSD - press and hold the MENU-button

while the monitor is off and then press power button to turn the monitor on.

Notes:

1. If the product has only one signal input, the item of "Input Select" is disabled.

2. If the product screen size is 4:3 or input signal resolution is native resolution, the item of "Image Ratio" is

disabled.

3. One of Clear vision, DCR, Color Boost, and Picture Boost functions is activated; the other three functions are

turned off accordingly.

Questions and Answers:

Need help?

Do you have a question about the AOC I2475PXQU and is the answer not in the manual?

AOC I2475PXQU Specifications

General

3D	No
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Pixel frequency	170 MHz
Display diagonal	23.8 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	296.46 mm
Contrast ratio (dynamic)	200000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
Active display area (W x H)	527.04 x 296.46 mm
Mean time between failures (MTBF)	50000 h
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.1
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	4
Certification	ISO
Product color	Black
Market positioning	Business
Pivot angle	- °
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Number of OSD languages	18
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
RMS rated power	2 W
Number of speakers	2
Thin client installed	-
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (standby)	0.3 W
Power consumption (typical)	14.8 W
Package depth	420 mm
Package width	693 mm
Package height	184 mm
Package weight	7700 g
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Harmonized System (HS) code	85285210
