AOC L22DK99U

28
3. No display (for 22”)
Check the B/L signal
is available?
Replace main board
Replace the power board
Vcc =5V?
Replace the Panel
No display (LED green)
Replace the main board
Check the backlight is “On”?
Check the LVDS cable
Reinsert or replace the
LVDS cable
Replace the main board
Replace the Panel
No
Yes
Yes
No
Yes
No
No
Yes
Yes
No
Yes
No
Power board output＝16V?
Check TV is under control and power on/off
by remote control and power key?
