AOC L22W831 Service Manual

22″LCD TV AOC L22W831
47
R06
061T0603330 1F
RST CHIPR 3.3 KOHM +-1% 1/10W
R07
061T0603680 1F
RST CHIPR 6.8 KOHM +-1% 1/10W
ZD05
093T 39S 34 T
UDZSNP5.6B ROHM
ZD06
093T 39S 34 T
UDZSNP5.6B ROHM
ZD07
093T 39S 34 T
UDZSNP5.6B ROHM
715T2927 2
KEY BOARD PCB
705TQ834304
STAND ASS`Y CKD
0M1T1740 8120
SCREW 42-D020715
A34T0524 GM 1L0100
STAND
A34T0525 GM 1L0100
BASE_S1
A37T0056013CKD
HINGE ASS'Y
Q12T6600 6
RUBBER FOOT
705TQ834305
REAR COVER ASS`Y
A15T0315101CKD
VESA BKT CKD
A34T0527 GM 3A0100
REAR COVER
Q36T 600 30 1
NONWOVEN FABRIC
E750
750TVCB6WA133N
PANEL CLAA220WA01 032 FZ CPT(2ND
SOURCE)
A15T0309101CKD
MAINFRAME
A15T0354201CKD
SIDE BKT CKD
A33T0332AEU 1C0100
IR LENS-A2
A34T0526 GMB2L0100
BEZEL 216W-8A2 CKD
AM1T1740 10225 CR3
SCREW
CBPF8A1SQ8
MAIN BOARD T2899-1-X-X-13-080604
CN700
033T327812D
WAFER 12P PLUG
CN600
033T3802 4B Y
CONNECTOR
CN400
033T380210B Y
CONNECTOR
CN402
033T8027 30
WAFER
040T 45762412B
CBPC LABEL
R627
061T153M399 59
3.9 OHM+-5% 3W
R626
061T153M399 59
3.9 OHM+-5% 3W
R624
061T153M399 59
3.9 OHM+-5% 3W
R623
061T153M399 59
3.9 OHM+-5% 3W
R138
061T175L22052T
22 OHM 5% 1/2W
R137
061T175L39052T
39 OHM 5% 1/2W
C652
067T 305102 4
105C 1000UF +-20% 25V
C702
067T215P4713AV
CAP 105℃ 470UF M 16V
C706
067T215P4714AV
CAP 105℃ 470UF M 25V
C132
067T305V471 4
EC 470UF 25V KM 10X16MM V
CN105
088T 78 1357S
RCA JACK 1*1 W+R V/A
CN103
088T 78 13932 S
RCA JACK + S JACK Y/B
CN102
088T 78 V5 C
RCA JACK 3+2 G/BLU/R+W/R
CN602
088T 30211K
PHONE JACK
CN100
088T 30252S
PHONE JACK 3.5MM 3P V/A GREEN
CN104
088T 35315F VC
D-SUB 15PIN VERTICAL CONNECTOR
090T 372 2
HEAT SINK
X600
093T 2270B H
XAT024576FK1H-3OHX AT-49 24.576MHZ
TU101
094TNTSC MN 7L
TUNER M15WPP-4N-E
705TQ856001
U602 ASS'Y
U602
056T 616511 ST
IC TDA7297SA ST
0M1T1730 10120
SCREW
