AOC L22W831 Service Manual

22″LCD TV AOC L22W831
46
11. BOM List
E228CANSW8AE3N
Location
Part No.
Description
007T 5 1 A
COMPOUND PALLET
026T 800504 3
BARCODE LABEL
040T 154501 1
HI-POT GND LABEL
040T 581 26646
S/N LABEL
045T 77 3
PE PACKING
045T 77500
RIBBON
045T 77501
RIBBON
049T 51 1A
ERADICATOR
051T6001 2
DESICCANT
052T 1150 C
BLACK TAPE
052T 1185
MIDDLE TAPE FOR CARTON
052T 1186
SMALL TAPE
052T 1210 A
ALUMINIUM TAPE
052T 1211 B
ADHESIVE TYPE
052T 2191 A
TAPE
E078
078T 494511 Y
SPK 8 OHM 3.5W 25X80 150 150MM SUNLINK
089T 17356C553
AUDIO CABLE
089T402A15NIS1
POWER CORD
E09502
095T801410D597
WIRE HARNESS 10P-5P+5P(A1253HA
HR)(2ND SOURCE)
E09502
095T801410W597
WIRE HARNESS 10P-5P+5P(A1253HA HR)
095T8018 3X698
LVDS CABLE
0D1T 930 6120
SCREW
0D1T 930 8 47 CR3
SCREW
0M1T1730 6120
SCREW 3*6MM
0M1T1730 8120
SCREW
0M1T1730 8120
SCREW
0M1T1730 10120
SCREW
0Q1T 930 6120
SCREW
0Q1T 930 8 47 CR3
SCREW
0Q1T 940 10 47 CR3
SCREW
0Q1T1030 6120
SCREW
705TQ833045
PLASTIC ASS`Y
0Q1T 930 6120
SCREW
A33T0305 GM 1L0100
BUTTON_FUNC
A33T0309 GMA1L0100
COVER_FUNC
KEPF8QA8
KEY BOARD
CN01
033T3802 5B YH W
WAFER
SW02
077T 600 1GCJ
TACT SWITCH TSPB-2 -NP
SW01
077T 600 1GCJ
TACT SWITCH TSPB-2 -NP
SW06
077T 600 1GCJ
TACT SWITCH TSPB-2 -NP
SW07
077T 600 1GCJ
TACT SWITCH TSPB-2 -NP
SW04
077T 600 1GCJ
TACT SWITCH TSPB-2 -NP
SW05
077T 600 1GCJ
TACT SWITCH TSPB-2 -NP
SW03
077T 600 1GCJ
TACT SWITCH TSPB-2 -NP
R05
061T0603000
RST CHIPR 0 OHM +-5% 1/10W
R09
061T0603154
RST CHIPR 150 KOHM +-5% 1/10W
R08
061T0603220 2F
RST CHIPR 22 KOHM +-1% 1/10W
