19
2) With HDMI-DVI Cable:
Connect the HDMI-DVI cable from the DVI output of the computer to the HDMI terminal input
of the LCD TV. Also, connect the green end of the Audio In cable from the audio output of your
computer to the audio input terminal (red/white) of the LCD TV.
Connecting with the power cord
Connect the power cord to the AC inlet on the back of your LCD TV, after all connections have
been completed, and plug the other end of the power cord into a correctly grounded electrical
outlet.
HDMI-DVI Cable (not supplied)
PC
Audio In Cable (not supplied)
A
C power socket
Power Cord

AOC L24H898 Specifications

General

Power LED	Yes
Pixel pitch	0.2715 x 0.2715 mm
Cable lock slot	No
Display diagonal	23.6 \
Display brightness	300 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Supported video modes	1080p
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	10000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
Package depth	145 mm
Package width	620 mm
Package height	510 mm
Package weight	9000 g
Certification	FCC, cULus, RoHS, EPA3.0
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Audio (L/R) in	1
SCART ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
LED indicators	Stand-by
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	75 W
RMS rated power	10 W

Weight and Dimensions

Depth (with stand)	216 mm
Width (with stand)	566.7 mm
Height (with stand)	442.7 mm
Weight (with stand)	7000 g
Depth (without stand)	86 mm
Height (without stand)	386.7 mm
