32’’ LCD TV AOC L32W665
56
 705TQ734134 REAR COVER ASS'Y
 A33T0138 GMB1L 30 COVER_FUNCTION
 A33T0139 AI 1L BUTTON_FUNCTION
 A33T0140 GMA1A SIDE COVER
 A34T0217 GM 2A 30 REAR COVER 32
 KEPF6AA6 KEY BOARD
CN21 033T8027 8 H WAFER
SW25 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW26 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW27 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW23 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW24 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW22 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW21 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
C24 065T0603104 32 CHIP 0.1UF 50V X7R
C25 065T0603104 32 CHIP 0.1UF 50V X7R
C26 065T0603104 32 CHIP 0.1UF 50V X7R
C21 065T0603104 32 CHIP 0.1UF 50V X7R
C22 065T0603104 32 CHIP 0.1UF 50V X7R
C20 065T0603104 32 CHIP 0.1UF 50V X7R
C23 065T0603104 32 CHIP 0.1UF 50V X7R
 715T2470 1 KEY BOARD PCB
 PTPF6AA6 SIDE BOARD
CN004 033T380214H WAFER
CN011 088T 78 1319C RCA JACK 1*3 R/W/Y
CN003 088T 100 11 ST MINI DIN JACK 4P+ SWITCH 2MJ-0602-005
CN010 088T 30211K PHONE JACK
R111 061T0603000 CHIP 0OHM 1/16W
R112 061T0603000 CHIP 0OHM 1/16W
R113 061T0603000 CHIP 0OHM 1/16W
R001 061T0603473 CHIP 47KOHM 1/16W
R002 061T0603473 CHIP 47KOHM 1/16W
R003 061T0603473 CHIP 47KOHM 1/16W
R004 061T0603473 CHIP 47KOHM 1/16W
C101 065T0603101 31 CHIP 100PF 50V NPO
C102 065T0603101 31 CHIP 100PF 50V NPO
C103 065T0603101 31 CHIP 100PF 50V NPO
C104 065T0603101 31 CHIP 100PF 50V NPO
C105 065T0603101 31 CHIP 100PF 50V NPO
C106 065T0603101 31 CHIP 100PF 50V NPO
C107 065T0603101 31 CHIP 100PF 50V NPO
C109 065T0603102 32 CHIP 1000PF 50V X7R
C108 065T0603102 32 CHIP 1000PF 50V X7R
FB002 071T 56G301 EA CHIP BEAD 300 OHM 0805
FB001 071T 56G301 EA CHIP BEAD 300 OHM 0805
ZD001 093T 39147SEM ZMM5V6
Z007 093T 64 37 N V-PORT-0603-100K V05
Z006 093T 64 37 N V-PORT-0603-100K V05
Z005 093T 64 37 N V-PORT-0603-100K V05
Z004 093T 64 37 N V-PORT-0603-100K V05
Z003 093T 64 37 N V-PORT-0603-100K V05
