AOC L42H961

42ƎLCD TV AOC L42H961
78
9.5 IR Board 715G3394 2
D01 LED
1 3
2
R001 NC/ 22K 1/10W 5%
LED_R
GND_PIN GND PIN
1
C02 0.1uF/16V
CN01 CONN
1 2 3 4 5 6
7 8
RED
81G 12 10 EL
56G 627 42
33G8032 6F HR
C01 NC/ 3.3uF/10V
U02
KSM-603TM2E
1 2 3
VOUT GND VCC
U01 LED GPB2603C/R001-HB
12
C03 NC/4.7uF/16V
R003 15K 1/8W 5%
LED_B
D3V3
GREEN
IRRV
R002 NC/ 22K 1/10W 5%
LIGHT_SENSOR
D3V3
B
Custom
22Wednesday, May 06, 2009
715G3394
<
⿄⠍
>
02-IR&LED
OEM MODEL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
⿄⠍
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
㍀
