47
7. Adjustment
ADC Adjustment
1. Factory Mode
Turn on the TV. Press menu key and then press number key 1+9 +9+9+back. It will achieve the factory mode.
2. ADC Adjustment (It’s no need to adjust ADC.)
3. White Balance Adjustment
(1) Enter into the factory mode;(same as the above-mentioned).
(2)Take an example of adjust Ypbpr source.
a. Select item “Source”: Ypbpr and item “Color Temp”: Normal, Adjust gain of RGB to meet spec in the below
setting of Tim\pat. (COMPONENT mode: TIM = 314; PAT = 141(80IRE))
b. Select item “Source”: Ypbpr and item “Color Temp”:Warm, Adjust gain of RGB to meet spec in the below setting
of Tim\pat. (COMPONENT mode: TIM = 314; PAT = 141(80IRE))
c. Select item “Source”: Ypbpr and item “Color Temp”: Cool, Adjust gain of RGB to meet spec in the below setting
of Tim\pat. (COMPONENT mode: TIM = 314; PAT = 141(80IRE))
(3) Take an example of adjust VGA Normal:
a. Select item “Source”: VGA and item “Color Temp”: Normal, Adjust gain of RGB to meet spec in the below
setting of Tim\pat. (VGA mode: TIM = 137; PAT = 141(80IRE)
b. Select item “Source”: VGA and item “Color Temp”: Warm, Adjust gain of RGB to meet spec in the below setting
of Tim\pat. (VGA mode: TIM = 137; PAT = 141(80IRE)
c. Select item “Source”: VGA and item “Color Temp”: Cool, Adjust gain of RGB to meet spec in the below setting of
Tim\pat. (VGA mode: TIM = 137; PAT = 141(80IRE)
(4)Take an example of adjust AV Normal:
a. Select item “Source”: AV and item “Color Temp”: Normal, Adjust gain of RGB to meet spec in the
below setting of Tim\pat. (AV mode: TIM = 303; PAT = 141(80IRE)
b. Select item “Source”: AV and item “Color Temp”: Warm, Adjust gain of RGB to meet spec in the below setting of
Tim\pat. (AV mode: TIM = 303; PAT = 141(80IRE)
c. Select item “Source”: AV and item “Color Temp”: Cool, Adjust gain of RGB to meet spec in the
below setting of Tim/pat. (AV mode: TIM = 303; PAT = 141(80IRE)
(5) Take an example of adjust HDMI Normal:
a. Select item “Source”: HDMI and item “Color Temp”: Normal, Adjust gain of RGB to meet spec in the below setting
of Tim\pat. (HDMI mode: TIM = 347; PAT = 141(80IRE)
b. Select item “Source”:HDMI and item “Color Temp”: Warm, Adjust gain of RGB to meet spec in the below setting of
Tim\pat. (HDMI mode: TIM = 347; PAT = 141(80IRE)
c. Select item “Source”: HDMI and item “Color Temp”: Cool, Adjust gain of RGB to meet spec in the
below setting of Tim/pat. (HDMI mode: TIM = 347; PAT = 141(80IRE)
4.The following color specifications for reference, to RD engineering specifications.
Source VGA/YPbPr/AV/HDMI VGA/YPbPr/AV/HDMI VGA/YPbPr/AV/HDMI
Temp Normal/(7500K) Warm/(6500K) Cool/(9300K)
x (center) 0.285 0.020 0.313 0.020 0.272 0.020
y (center) 0.293 0.020 0.329 0.020 0.278 0.020
Note: all models of color temperature within specification, but also ensure the brightness conform to engineering
specifications.
