11. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice.
Please go to http://cs.tpv.com.cn/hello1.asp
for the latest information.
LC32D1320 E32BATNSW3B13N
Location Part No. Description Remark
705TQBBCA92 705 ASS'Y FOR BRAZIL PCBA
756TXCCB0TS0020001 MAIN BOARD-CBPFBTASX2C
U115 056G1133956 IC CAT24C02WI-GT3 SO-8
U405 056G2233 50 FLASH H27U1G8F2BTR-BC 1GB TSOP1-48
U406 056G2233X01 FLASH MX25L4006EM2I-12G 4M SOP8L 200 MIL
SMTF-U405 100TATAK017S1X MCU ASS'Y-056G2233 50
SMTF-U406 100TATAK018S1X MCU ASS'Y-056G2233X01
SMTF-U115 100TATAK019S1X MCU ASS'Y-056G1133956
Z40G0002ALL01A SFIS LABEL 35MM*9MM
CN401 033G380214B Y CONNECTOR
C721 067G305S3316CT EC 330UF 20% 35V KW 10*9
C716 067G305S3316CT EC 330UF 20% 35V KW 10*9
C6002 067G305S3316CT EC 330UF 20% 35V KW 10*9
C721 067G305S3316CV EC 330UF 20% 35V 10*9
C716 067G305S3316CV EC 330UF 20% 35V 10*9
C6002 067G305S3316CV EC 330UF 20% 35V 10*9
C651 067G315M1016HE EC 100UF 20% 35V 8*7
C1108 067G315M1016HE EC 100UF 20% 35V 8*7
C651 067G315M1016KE EC 100UF 20% 35V 8*7 3000 HR
C1108 067G315M1016KE EC 100UF 20% 35V 8*7 3000 HR
CN605 088G 78F111VCL RCA JACK V/T 2P BLACK 1*1 H=8.6
CN605 088G 78F111VYG RCA JACK V/T 2P BLACK 1*1 H=8.6
CN116 088G 78F121XCL RCA JACK V/T 4P W/R 1*2 H=8.6
CN111 088G 78F135XCL RCA JACK V/T 6P G/BL/R 1*3 H=8.6
CN102 088G302F3G1VCL PHONE JACK V/T 3P GREEN H=8.4
CN602 088G302G7B1ACL PHONE JACK R/A 7P BLACK H=10.5
CN103 088G352F6B2ACL USB CONN R/A 6P BLACK 8.4MM
CN101 088G353FFF1XCL D-SUB CONN SCREWED V/T 15P BLUE H=8.6
TU102 094G PALISBM2P TUNER USA FK1604
CN601 311GW250B04BBX WAFER 2.5MM 4P
CN701 311GW250B13BBX WAFER 2.5MM 13P R/A 35MM 7MM
709T4786 XM001 COMSUMPTIVE ASS'Y
055G 23524 WELDING FLUX WITHOUT PB
Q55G 100620500 TIN STICK(SN-0.5AG)
X90T8018 1 HEAT SINK
040G 457624 1B LABEL-CPU
U605 056G 158501 IC AS431AN-E1 SOT23
U401 056G 562467 SCALER TSXL28-B1A10-H BGA
U705 056G 563121 LDO G1084-33TU3UF 5A 3.3V TO-263T
U702 056G 563121 LDO G1084-33TU3UF 5A 3.3V TO-263T
U704 056G 563122 IC G1084-25TU3UF TO-263T
U703 056G 563143 IC G1084T43UF TO-252
U708 056G 563146 LDO G912T63U 1A 1.2V SOT-223
U709 056G 563149 IC G903T63UF 0.6A/3.3V SOT-223
U1101 056G 563172 DC/DC G5655P12U 2A SOP-8
U706 056G 563186 DC/DC CONVERTER IC G5684F11U SOP8
U701 056G 563X01 LDO G9661-25ADJF11U 2A 300MV DROP SOP-8
