LC42D1320
Item Description
1 BEZEL
2 Key cover
3 Key button
4 KEY BOARD
5 IE Lens
6 Led Lens
7 IR BOARD
8 SPEAKER
9 PANEL
10 BKT-PANEL-TOP
11 42-bkt-pb
12 BKT-MB-L Item Part No. Description Qty
13 BKT-MB-R 26 0Q1G 930 8 47 CR3 SCREW(REAR COVER-IO) 1
14 BKT-STAND 27 0Q1G1030 6120 SCREW(IR BOARD) 1
15 POWER BOARD 28 001G6021 1 screw(SPEAKER) 4
16 MAIN BOARD 29 0Q1G 940 16 47 CR3 SCREW(BKT) 4
17 IO BKT 30 0M1G 940 6120 SCREW(BKT) 12
18 LABEL SIDE IO 31 0M1G 930 6 47 CR3 SCREW(BKT) 2
19 HINGE ASS'Y 32 0M1G1730 10120 SCREW(POWER BOARD/MAIN BOARD) 9
20 BKT-VESA-BTM 33 0M1G1740 8225 CR3 SCREW( BKT STAND-HINGE) 2
21 BASE 34 0Q1G 940 18 47 CR3 screw(REAR COVER) 10
22 Rear Cover 35 0Q1G 940 30 47 CR3 SCREW(REAR COVER) 4
23 BACK IO LABEL 36 0M1G 940 8 47 CR3 SCREW(REAR COVER) 4
24 bkt-base-a2 37 0M1G1430 8 47 CR3 SCREW(REAR COVER-HDMI) 1
25 FOOT PAD 38 0M1G1740 14120 SCREW(STAND BKT) 2
41 bkt-fix-panel 39 0Q1G 130 8 47 CR3 SCREW(BASE-BASE ) 6
42 bkt-fix-s 40 Q01G6145 1 SCREW(BASE-BKT BASE) 4
43 bkt-fix 44 0Q1G 930 8 47 CR3 SCREW(BKT) 2
