AOC LC32D1320 User Manual

76
LC32D1320
Item Description
1 BEZEL
2 Key cover
3 Key button
4 KEY BOARD PCB
5 LENS IR
6 POWER LENS
7 IR BOARD PCB
8 SPEAKER
9 PANEL
10 DAUGHTER BOARD PCB
11 BKT-PANEL-SUPPORT-TOP
12 BKT_VESA
13 BKT_PCB_MAINBD_L
14 BKT_PANEL_L
15 BKT_PANEL_BTM
16 BKT_PCB_MAINBD_L
17 BKT_PCB_MAINBD_R
Item Part No. Description Qty
18 MAIN BOARD PCB 30 0Q1G1030 6120 SCREW(IR BOARD) 1
19 BKT_IO 31 001G6021 1 screw(SPEAKER) 4
20 BKT_BASE 32 0M1G1730 8120 SCREW(DAUGHTER BOARD) 2
21 LABEL IO SIDE 33 0Q1G 940 14 47 CR3 SCREW(PANEL BKT) 2
22 POWER BOARD PCB 34 0M1G 940 14 47 CR3 SCREW(PANEL BKT) 4
23 BKT_VESA_BTM 35 0M1G 940 6120 SCREW(PANEL BKT) 13
24 LABEL IO BACK 36 0M1G1730 8120 SCREW(POWER BOARD/PANEL/MAIN BOARD) 8
25 REAR COVER_32" 37 0M1G1730 10120 SCREW(POWER BOARD) 1
26 BASE HINGE_COVER 38 0M1G 940 14 47 CR3 SCREW(REAR COVER) 6
27 BASE STAND_COVER 39 0Q1G 940 16 47 CR3 SCREW(REAR COVER) 10
28 base 40 0Q1G 930 8 47 CR3 SCREW(REAR COVER/IO) 1
29 FOOT PAD 41 0M1G 930 8 47 CR3 SCREW(REAR COVER/HDMI) 1
