AOC LC42H163 User Manual

21
3.3 Compatible Mode Table
Tabla de señales de entrada de PC
Una vez que el PC está conectado al televisor, configure la señal de salida desde el PC, de acuerdo a la siguiente
tabla.
Configuración del Modo PC
Estándar Resolución Frecuencia horizontal (kHz) Frecuencia Vertical (kHz)
VESA 640 x 480 31.469 59.940
VESA 720 x 400 31.469 70.087
VESA 800 x 600 37.879 60.317
VESA 1024 x 768 48.363 60.004
VESA 1280 x 720 44.772 59.855
VESA 1280 x 768 47.396 59.995
VESA 1280 x 1024 63.981 60.020
VESA 1440 x 900 55.469 59.901
VESA 1680 x 1050 65.290 59.954
VESA 1920 x 1080 67.500 60.000
Tabla de Referencia de Señal de Entrada de Video
Tras conectar la entrada de video al televisor, configure la señal de salida desde la entrada de video según la tabla
siguiente.
Configuración del Modo Video
Estánda Resolución Frecuencia horizontal (kHz) Frecuencia Vertical (kHz)
SD 480i 15.75 60
SD 480P 31.5 60
HD 720P 45 60
HD 1080i 33.75 60
FHD 1080p 67.5 60
Interfaz de definición estándar
También puede disfrutar de la programación tradicional a través de un reproductor de DVD o de una
videograbadora. Conecte este equipo a su televisor mediante la entrada de video compuesto (COMPOSITE) en la
parte posterior de su televisor.
Cuando conecte otros equipos a su televisor, consulte la Guía de Configuración rápida (incluida).
