AOC LE20A1140 User Manual

59
E715 715G5772R01000004S IR BOARD PCB 2nd Source
PLTVDC421XXC1Q ADAPTER BOARD
Z40G0002ALL01A OTHER LABEL
CN8102 033G8021 2E L INVERT CONN 3.5mm 2P
CN8102 033G8021 2E XY CONNECTOR
IC9102 056G 139 8 Photo-Coupler PS2561DL1-1 CTR Q100~200%
IC9102 056G 139 9 IC EL817M(X) photocoupler DIP-4
C9901 063G107M47410M CAP X2 470NF 20% 275V R46KI3470HAP1M
FB9904 071G 55 21 H1 BEAD 6.0*10 700R 25% BF-I60100R-706B
FB9909 071G 55 21 H1 BEAD 6.0*10 700R 25% BF-I60100R-706B
FB9901 071G 55906 H BEAD 6.0*9.2 510R MIN BF-I60090C-794
FB9902 071G 55906 H BEAD 6.0*9.2 510R MIN BF-I60090C-794
L9901 073G 174192 L LINE FILTER 30MH MIN LF-013589-2
L9901 073G 174192 X LINE FILTER 30MH MIN ET20 0.8A
L8102 073G 253214 H CHOKE COIL 47UH 10% L470R HA
L8102 073G 253214 X CHOKE COIL 47UH 10% ,HF
F9901 084G 41 15 C FUSE 3.15A 250V UDA-A3.15(PF)
F9901 084G 41 15 L FUSE 3.15A 250V 0215 3.15MXEP
CN9901 087G 50147C DL AC SOCKET V/T 2P ACT1MD-02BL4B006 H=14
CN9901 087G 50147C HC AC socket V/T 2P DB-8-01 H=14mm
BD9101 093G 50460 44 BRIDGE GBL408 4A/800V GBL
BD9101 093G 50460 50 BRIDGE GBL08 4A/800V GBL
D9108 093G 60334 SCHOTTKY SR506-44 5A 60V DO-201AD
D9109 093G 60334 SCHOTTKY SR506-44 5A 60V DO-201AD
D9113 093G 60335 HF SCHOTTKY SR515-04 X0G 5A 150V DO-201AD
D9111 093G 60335 HF SCHOTTKY SR515-04 X0G 5A 150V DO-201AD
0Q1G 340 8140 SCREW Q1-SELF TAPING SCREW :Q x8.0
CN9904 311GW250B13BBX WAFER 2.5mm 13P R/A 35mm 7mm
RV9901 361G0046621KZE VARISTOR 620V 10%
NR9902 361G0058159LAW005A NTCR 1.5R 15% 2.4W SCK101R55LJY501,1.5D
NR9901 361G0058159LAW005A NTCR 1.5R 15% 2.4W SCK101R55LJY501,1.5D
C9101 367G215X470PHZ002S EC 47UF 20% 450V 12.5*35 2000 hr 420mA H
C9102 367G215X470PHZ002S EC 47UF 20% 450V 12.5*35 2000 hr 420mA H
C9102 367G215X470PKZ002S .C 47UF 20% 450V 12.5*36 2000 hr 420mA P
C9101 367G215X470PKZ002S .C 47UF 20% 450V 12.5*36 2000 hr 420mA P
L9101 373G0253247H00 CHOKE COIL 3UH 15% DR8*8 5A
L9102 373G0253247H00 CHOKE COIL 3UH 15% DR8*8 5A
L9102 373G0253247X00 CHOKE COIL 3UH 15% DR8*8 5A
L9101 373G0253247X00 CHOKE COIL 3UH 15% DR8*8 5A
T9101 380GL19P049H00 X'FMR 800uH 8% 20 EFD30 BCK-13030-HA
T9101 380GL19P049N00 X'FMR 800uH 8% 20uH EFD30 YUVA-1952-1
D8101 393G0060A0400T SCHOTTKY SR310-29 X0 3A 100V DO-201AD
705TAD5700600Q Q9101 ASS"Y
Q9101_1 0M1G1730 8120 SCREW
Q9101 357G0667A11 MOSFET STF6N65K3 5.4A 650V 30W TO-220FP
HS9101 Q90G0219 4 HEAT SINK ÐͲÄ/Profile
IC9103 056G 158501 IC AS431AN-E1 SOT23
IC8501 056G 700 34 LED DRIVER PF7001S SOP-14
Q8101 057G 763125 .OSFET AO4486 4.2A 100V SO-8
R8129 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA
R8130 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA
R9143 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA
R8103 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA
R8131 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA
