LE24H138
Item Description
1 BEZEL
2 TOUCH KEY
3 LENS _IR
4 IR BOARD
6 PANEL
7 MYLAR
8 POWER BOARD
10 MAIN_FRAME
11 AC COVER
12 MAIN BOARD
13 BRACKET _SIDE_IO_HIMAX
Item Part No. Description Qty
15 SPEAKER 5 0Q1G 930 8 47 CR3 SCREW(IR BOARD/BEZEL) 1
16 LENS _POWER 9 0M1G1730 8120 SCREW(POWER BOARD/MAIN_FRAME/MAIN BOARD/LED BOARD) 9
17 LED BOARD 14 0M1G1830 6120 SCREW(SPEAKER/MAIN_FRAME) 4
21 STAND 18 0M1G 940 8 47 CR3 SCREW(AC COVER/MAIN_FRAME) 1
22 PLATE _STAND 19 0Q1G 930 6120 SCREW(BEZEL/MAIN_FRAME) 2
23 FOOT PAD 25 0Q1G 930 10 47 CR3 SCREW(REAR COVER/COVER IO) 3
24 FOOT PAD 30 0Q1G 930 10 47 CR3 SCREW(REAR COVER/BEZEL) 2
26 REAR COVER 31 0Q1G 930 26 47 CR3 SCREW(REAR COVER/COVER IO) 2
27 VEAS-BKT 32 0Q1G 930 20 47 CR3 SCREW(COVER IO) 1
28 COVER IO 33 0M1G 930 8 47 CR3 SCREW(COVER IO) 1
To Next Page
