3.3 Compatible Mode Table
Analog RGB Input Signal
Horizontal Vertical
Resolution
Nominal
Frequency(KHz)
Sync
Polarity
Nominal
Freq. (Hz)
Sync
Polarity
Nominal Pixel
Clock (MHz)
640x480@60Hz 31.469 - 59.940 - 25.175
720x400@70Hz 31.469 - 70.087 + 28.322
800x600@60Hz 37.879 + 60.317 + 40.000
1024x768@60Hz 48.363 - 60.004 - 65.000
1280x720@60Hz 44.772 - 59.855 + 74.500
1280x768@60Hz 47.396 - 59.995 + 68.250
1280x1024@60Hz 63.981 + 60.020 + 108.000
1440x900@60Hz 55.469 + 59.901 - 88.750
1680x1050@60Hz 65.290 - 59.954 + 146.250
1920x1080@60Hz 67.500 + 60.000 + 148.500
HDMI Input Signal
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
(KHz)
Sync
Polarity
Nominal
Freq.
(Hz)
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
VGA 640x480@60Hz 800x525 31.469 N 59.940 N 25.175
DOS 720x400@70Hz 900x449 31.469 N 70.087 P 28.322
SVGA 800x600@60Hz 1056x628 37.879 P 60.317 P 40.000
XGA 1024x768@60Hz 1344x806 48.363 N 60.004 N 65.000
WXGA 1280x768@60Hz 1312x800 47.396 P 59.995 N 68.250
CVT-0.92M 1280x720@60Hz 1664x748 44.772 N 59.855 P 74.500
SXGA 1280x1024@60Hz 1688x1066 63.981 P 60.020 P 108.000
WXGA+ 1440x900@60Hz 1600x926 55.469 P 59.901 N 88.750
WSXGA+ 1680x1050@60Hz 2240x1089 65.290 N 59.954 P 146.250
FHD 1920x1080@60Hz 2200x1125 67.500 P 60.000 P 148.500
480i 720x480i 15.75 60 13.513
480P 720x480P 31.50 60 27.027
720P 1280x720P 45.00 60 74.25
1080i 1920x1080i 33.75 60 74.25
1080P 1920x1080P 67.5 60 148.5
1080P 1920x1080P 27 24 74.25
