7. Adjustment
Introduction of adjust item:
They only need adjust WB(Ypbpr’s Normal/Warm/Cool).
Content of WB Adjustment
1. Enter into the factory mode:MENU+1+9+9+9+PRE CH
2. Take an example of adjust Ypbpr_Normal:
a. Select item “Source”: Ypbpr and item “Color Temp”: Normal.
b. Adjust gain of RGB to meet spec in the below setting of tim\pat.
(COMPONENT mode: TIM = 314; PAT = 141(80IRE))
3. Check the colour temperature of other “Source”ˈ
If the colour temperature can’t meet specˈplease adjust it
(VGA mode: TIM = 137; PAT = 141(80IRE)).
Normal/(7500
K) Warm/(6500
K) Cool/(9300
K)
x (center) 0.285 r 0.030 0.313 r 0.030 0.270 r 0.030
y (center) 0.293 r 0.030 0.329 r 0.030 0.273 r 0.030
Lv(center) >300cd >300cd >300cd
