AOC LE32A0321 - Page 48

48
9.4 IR Board 715G5471R02000004S
U201 IRM-H636M3/TR2
GND
1
GND
2
OUT
3
VCC
4
IR
033G8032 5F HR
C201 0.1uF 50V
VCC
R201 15K 1/10W
081G 14 24 EL
OEM MODEL
Size Rev
Date
Sheet
of
TPV MODEL
PCB NAME
⿄⠍
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
㍀
䱨
⪰
㌾
㝍
Dynex UFC Model
A
X
A
22Wednesday , January 18, 2012
715G5471-R0A-000-0040
<
⿄⠍
>
02-IR&LED
715G5471-R0A-000-0040
R203 220 OHM 1/10W
LED_B
CN201
CONN
1 2 3 4 5
67
LED_R
RED
BLUE
LED201 LED
1 23
4
R202 220 OHM 1/10W
Dip LED
Top View
IR
16 mm
37mm
