50
LE32A0321
Item Description
1 BEZEL
2 DECO_BEZEL
3 SPEAKERS
4 PANEL TPT315B5-TAT01
5 BKT_STAND(PANEL)
6 COVER_STAND
7 DECO_KEY
8 REAR_COVER
9 BASE
10 KEY BOARD
11 IR BOARD
12 MAIN BOARD
13 BKT_IO
14 ADAPTER BOARD
15 BOLT
Item Part No. Description Qty
16 BKT_BTM 22 0M1G1030 8 47 CR3 SCREW(REAR_COVER/PANEL) 8
17 INSULATING SHEET 23 0M1G1030 8 47 CR3 SCREW(REAR_COVER/DECO_BEZEL) 6
20 FOOT PAD 24 0M1G1730 8120 SCREW(MAIN BOARD/POWER BOARD/BKT_IO/BKT_BTM) 11
21 BKT_STAND 25 0M1G1740 10225 CR3 SCREW(BKT_BTM/COVER_HINGE/REAR_COVER) 8
29 COVER_HINGE 26 0Q1G 940 8 47 CR3 SCREW(REAR_COVER/PANEL) 2
30 BKT_STAND 27 0Q1G 940 12 47 CR3 SCREW(REAR_COVER/PANEL) 4
