LE39A0321
Item Description
1 BEZEL
2 PANEL
3 DECO_BEZEL-SHEET
4 DECO_BEZEL
6 IR BOARD
9 SPEAKERS
10 COVER_STAND
11 BKT_STAND
13 INSULATING SHEET
14 ADAPTER BOARD
17 BOLT
18 BKT_IO
Item Part No. Description Qty
20 MAIN BOARD 5 0M1G1030 6 47 CR3 SCREW(DECO_BEZEL/PANEL) 4
21 BKT_BTM 12 0M1G 940 6125 SCREW(BKT_STAND/BKT_HINGE) 4
22 BKT_HINGE 15 0M1G1730 8120 SCREW(POWER BOARD/PANEL) 5
23 COVER_HINGE 19 0M1G1730 6120 SCREW(PANEL/MAIN BOARD/BKT_IO/BKT_BTM) 4
24 BKT_STAND 27 0Q1G 130 6120 XL SCREW(BASE/BKT_BASE) 3
25 BASE 28 0M1G1740 10225 CR3 SCREW(BASE/BKT_BASE/COVER_HINGE) 4
26 BKT_BASE 30 0M1G1740 10225 CR3 SCREW(BKT_HINGE/BKT_STAND) 4
29 FOOT PAD 34 0M1G1030 6 47 CR3 SCREW(REAR_COVER/PANEL) 8
31 DECO_KEY 35 0Q1G 940 8 47 CR3 SCREW(REAR_COVER/DECO_BEZEL) 2
32 KEY BOARD 36 0Q1G 940 10 47 CR3 SCREW(REAR_COVER/DECO_BEZEL/STAND) 4
33 REAR_COVER 37 0M1G1030 6 47 CR3 SCREW(REAR_COVER/AC SOCKET) 1
