AOC LE32A0321 Service Manual

54
R203 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA 
C201 065G060310432K F CAP CHIP 0603 0.1UF K 50V X7R 
LED201 081G 14 24 EL CHIP LED BLUE/DARK RED 
U201 356GS927072 IR RECEIVER IRM-H638M3/TR2 38 KHz 
 709T54710XS001 COMSUPTIVE ASS'Y 
E715 715G5471R02000004S IR PCB FR4 DS 37X16X1.6MM 
 KEPFCXAE KEY BOARD 
CN01 033G8032 4F B CONN 1.25mm 4P R/A 9.95mm 5.7mm 
CN01 033G8032 4F X WAFER 4P 1.25MM 
R04 061G08051001FT RST CHIP 1K 1/8W 1% 
R03 061G08051801FY RST CHIP R 1K8 +/-1% 1/8W 
R02 061G08052701FY RST CHIP 2K7 1/8W 1% 
R06 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA 
R05 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA 
R07 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA 
R01 061G08057501FY RST CHIP R 7K5 1/8W +/-1% 
SW03 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL 
SW06 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL 
SW02 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL 
SW04 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL 
SW01 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL 
SW07 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL 
SW05 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL 
SW03 077G 607 2 HC TACT SW 4P 1.5mm 160g TS-4402-1.58B-01 
SW04 077G 607 2 HC TACT SW 4P 1.5mm 160g TS-4402-1.58B-01 
SW01 077G 607 2 HC TACT SW 4P 1.5mm 160g TS-4402-1.58B-01 
SW06 077G 607 2 HC TACT SW 4P 1.5mm 160g TS-4402-1.58B-01 
SW07 077G 607 2 HC TACT SW 4P 1.5mm 160g TS-4402-1.58B-01 
SW05 077G 607 2 HC TACT SW 4P 1.5mm 160g TS-4402-1.58B-01 
SW02 077G 607 2 HC TACT SW 4P 1.5mm 160g TS-4402-1.58B-01 
 709T57110XS001 COMSUMPTIVE ASSY 
 Q05G6054 1 SHEET 
 Q09G6012 1 PIN 
E715 715G5711K01000004S KEY PCB FR4 DS 12 X 125X1.6MM 
E750 LCE315TAT01AD8010X PANEL TPT315B5-TAT01 R00H XM TPV 
E750 LCE315TAT01AD8510X PANEL TPT315B5-TAT01 R00M XM TPV 
E750 LCV315TAT01AD8011X PANEL TPT315B5-TAT01 C1C XM TPV 
 P33T0408ADT01L0200 DECO_KEY 
 P34T12010GMY3K01BA REAR_COVER 
 P34T1202ADT01L01BG DECO_BEZEL 
 P34T12050GM01K0100 COVER_STAND 
 Q02G7060001001 BOLT 
M00201 Q02G706100200100HX BOLT 
M00201 Q02G706100200100XL BOLT 
 Q16G0001 10 12 EVA WASHER 
 Q16G0001 20 8 EVA 
 Q36T 600 37 26 GP NON-WOVEN FABRIC 
 Q45G99010TV03900WN PROTECT BAG 
 Q50G 4 10 TIE (Y1900221) 
 Q50G 500 TV005 CABLE TIE 
 Q52G1501150523 W INSULATING PLATE 
 Q52G1501150523AWYY TAPE_INSULATING 
 Q52G18010TV08200ZA INSULATING SHEET 
 X15T841310100000Z1 BKT_STAND 
