AOC LE32A0321 Service Manual

56
L9102 073G 253 91 V CHOKE COIL 3.5uH+-10% 
L9101 073G 253 91 V CHOKE COIL 3.5uH+-10% 
L8102 073G 253203 X CHOKE COIL 5uH 15% -- 
T9301 080GL52P 54 H X'FMR 1000uH 10% 40uH EQ30 BCK-13026-HA 
CN9901 087G 50147D HC AC SOKET R/A 2P 12DEGREE H=12.8 
D9107 093G 60334 SCHOTTKY SR506-44 5A 60V DO-201AD 
CN9901 0Q1G 340 8140 SCREW Q1-SELF TAPING SCREW :Q x8.0 
CN9902 311GW250B13BBX WAFER 2.5mm 13P R/A 35mm 7mm 
C9812 367G305X221PKZ000S EC 220uF 20% 450V 22*51 3000 hr 1.6A PW2 
L8101 373G0253249CP0 BOOST CHOKE 33UH 10% EQ25 0.5A L020692-6 
T9101 380GL32P106N00 X'FMR 750uH 10% 18uH ER28 YUVA-2016-4 
 705TXC57330 Q9101 Assy 
Q9101 057G 667 21 MOSFET STP10NK70ZFP 8.6A 700V TO-220FP 
 0M1G1730 8120 SCREW 3x8 
HS9101 Q90G0087 7 HEAT SINK ÆäËû/other 
 705TXC57331 Q8101 & D8103 Assy 
D8103 093G 60258 DIODE FME-220B TO-220 SANKEN 
 0M1G1730 8120 SCREW 3x8 
Q8101 357G0600980 MOSFET AOTF454L 13A 150V 41W TO-220F 
HS8101 Q90T0237 1 HEAT SINK 
 705TXC84040 F9901 Assy 
EF9901 084G 34 10 FUSE CLIP 
EF9901 084G 34 14 FUSE -- -- -- 
F9901 084G 41 3 C FUSE 3.15A 250V, Time Lag Fuse 
 705TXC93969 BD9901 Assy 
HS9901 090G6064 1 HEAT SINK 
BD9901 093G 50460925 BRIDGE TS6B06G-01 6A 800V KBJ 
 0M1G1730 8120 SCREW 3x8 
 705TXC93970 D9104 & D9105 Assy 
HS9102 090G6064 1 HEAT SINK 
D9105 093G 52 57 RECTIFIER FMXA-2202S 20A 200V TO-220F 
D9104 093G 52909 RECTIFIER SFF1006G 10A 400V ITO-220AB 
D9104 093G 220 24 DIODE FMX-23S SANKEN 
 0M1G1730 8120 SCREW 3x8 
 705TXC93971 D9106 & D9305 Assy 
HS9103 090G6064 1 HEAT SINK 
D9106 093G 60329 DIODE FMEN-220A 20A/100V TO-220 
D9305 093G 60987 SCHOTTKY FMEN-2308 30A 80V TO-22OF 
 0M1G1730 8120 SCREW 3x8 
IC8201 056G 158501 IC AS431AN-E1 SOT23 
IC9101 056G 379175 IC LD7523GS SOP-8 
IC8101 056G 700 40 LED DRIVER LD7400GS SOP-8 
Q9402 057G 417 4 PMBS3904/PHILIPS-SMT(04) 
Q9401 057G 419912 T TRANSISTOR 2SD1624T-TD-E PCP 
Q8302 057G 759 2A HF TANSISTOR 2N7002H SOT-23 
Q8201 057G 760 4A DTA144WN3/S SOT-23 
Q8202 057G 760 5A DTC 144WN3/S SOT-23 
Q9601 057G 769900 SMALLTRAN BCR1002N3 0.2A 50V SOT23 
Q8301 057G 769900 SMALLTRAN BCR1002N3 0.2A 50V SOT23 
R8302 061G0805000 JI RST 0805 MAX0.05R 5% 1/8W TA-I 
R9601 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I 
R8303 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I 
R9602 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I 
R9124 061G08051001FT RST CHIP 1K 1/8W 1% 
