AOC LE32A0321 Service Manual

63
D9802 093G 52905 DIODE FMNS-1106S TO-220 
 0M1G1730 8120 SCREW 3x8 
HS9801 Q90G6241 1 GP HEAT SINK 
 705TXC84040 F9901 Assy 
EF9901 084G 34 10 FUSE CLIP 
EF9901 084G 34 14 FUSE -- -- -- 
F9901 084G 41 3 C FUSE 3.15A 250V, Time Lag Fuse 
 705TXC93969 BD9901 Assy 
HS9901 090G6064 1 HEAT SINK 
BD9901 093G 50460925 BRIDGE TS6B06G-01 6A 800V KBJ 
 0M1G1730 8120 SCREW 3x8 
 705TXC93970 D9104 & D9105 Assy 
HS9102 090G6064 1 HEAT SINK 
D9105 093G 52 57 RECTIFIER FMXA-2202S 20A 200V TO-220F 
D9104 093G 52909 RECTIFIER SFF1006G 10A 400V ITO-220AB 
D9104 093G 220 24 DIODE FMX-23S SANKEN 
 0M1G1730 8120 SCREW 3x8 
 705TXC93971 D9106 & D9305 Assy 
HS9103 090G6064 1 HEAT SINK 
D9106 093G 60329 DIODE FMEN-220A 20A/100V TO-220 
D9305 093G 60987 SCHOTTKY FMEN-2308 30A 80V TO-22OF 
 0M1G1730 8120 SCREW 3x8 
IC8201 056G 158501 IC AS431AN-E1 SOT23 
IC9801 056G 379172 IC LD7591GS SOP-8 
IC9101 056G 379175 IC LD7523GS SOP-8 
IC8101 056G 700 40 LED DRIVER LD7400GS SOP-8 
Q9402 057G 417 4 PMBS3904/PHILIPS-SMT(04) 
Q9401 057G 419912 T TRANSISTOR 2SD1624T-TD-E PCP 
Q8302 057G 759 2A HF TANSISTOR 2N7002H SOT-23 
Q8201 057G 760 4A DTA144WN3/S SOT-23 
Q8202 057G 760 5A DTC 144WN3/S SOT-23 
Q9601 057G 769900 SMALLTRAN BCR1002N3 0.2A 50V SOT23 
Q8301 057G 769900 SMALLTRAN BCR1002N3 0.2A 50V SOT23 
R8302 061G0805000 JI RST 0805 MAX0.05R 5% 1/8W TA-I 
R9602 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I 
R9601 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I 
R8303 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I 
R9124 061G08051001FT RST CHIP 1K 1/8W 1% 
R8106 061G08051002FI RST 0805 10K 1% 1/8W 
R9401 061G08051002FI RST 0805 10K 1% 1/8W 
R9403 061G08051002FI RST 0805 10K 1% 1/8W 
R9111 061G08051002FI RST 0805 10K 1% 1/8W 
R8304 061G08051002FI RST 0805 10K 1% 1/8W 
R9130 061G08051002FI RST 0805 10K 1% 1/8W 
R9404 061G08051002FI RST 0805 10K 1% 1/8W 
R8207 061G08051002FI RST 0805 10K 1% 1/8W 
R9808 061G08051002FI RST 0805 10K 1% 1/8W 
R9803 061G08051002FI RST 0805 10K 1% 1/8W 
R8210 061G08051003FI RST 0805 100K 1% 1/8W 
R8211 061G08051003FI RST 0805 100K 1% 1/8W 
R8209 061G08051003FI RST 0805 100K 1% 1/8W 
C9123 061G0805103 JT RST 0805 10K 5% 1/8W 
C9112 061G0805103 JT RST 0805 10K 5% 1/8W 
R9812 061G08051302FI RST CHIPR 13KOHM +-1% 1/8W TA-I 
R9107 061G08052001FT RST CHIP 2K 1/8W 1% 
R9125 061G08052202FI RST 0805 22K 1% 1/8W 
R9108 061G08052209FT RST 0805 22R 1% 1/8W 
