AOC LE32D3142 User Manual

15
English
PC Input Signal Reference Chart
Connect a computer to your TV set and set up the computer output signal in accordance with table below.
Default computer mode
Standard Resolution Vertical Frequency(Hz)
VGA 640 x 480 60
VGA 720 x 400 70
SVGA 800 x 600 60
XGA 1024 x 768 60
WXGA(32”) 1280 x 768 60
SXGA(40”) 1280 x 1024 60
WXGA 1360 x 768 60
FHD(40”) 1920 x 1080 60
DVI/ PC HDMI Input Signal Reference Chart
1. When DVI port is being used: connect the DVI port of video device to your TV set with a DVI-to-HDMI line and set up the output signal of the video
device in accordance with table below.
2. When HDMI port is being used: connect the HDMI ports of your computer and TV set with one HDMI wire and set up the output signal of the video
device in accordance with table below.
Default computer Mode
Standard Resolution Vertical Frequency(Hz)
VGA 640 x 480 60
VGA 720 x 400 70
SVGA 800 x 600 60
XGA 1024 x 768 60
WXGA(32”) 1280 x 768 60
SXGA(40”) 1280 x 1024 60
WXGA
1360 x 768 60
FHD(40”) 1920 x 1080 60
Video Input Signal Reference Chart
1. Connect the component signal or HDMI port of video device to your TV set and set up the output signal of the video device in accordance with table
below.
2. If your computer display card supports signals of video format then you can set up following output signal.
Default Component or HDMI Mode
Standard Resolution Vertical Frequency (Hz)
SD 720 x 480i 60
SD 720 x 480p 60
SD 720 x 576i 50
SD 720 x 576p 50
HD 1280 x 720p 50
HD 1280 x 720p 60
HD 1920 x 1080i 50
HD 1920 x 1080i 60
FHD 1920 x 1080p 50
FHD 1920 x 1080p 60
Video systems supported by the TV,video modes
NTSC M,PAL M,PAL N.
Standard Definition Interface
You can also enjoy traditional program by using a DVD player or VCR Player. Connect this equipment to your TV via the Composite Input on the
back of your TV.
