720x480P
59.94/60Hz
● ● 31.54 60 27.03
720P 59.94/60Hz ● ● 45 60 74.25
1080i 59.94/ 60Hz ● ● 33.75 60 74.25
1080P 24Hz ● ● 67.5 24 59.4
1080P 60Hz ● ● 67.5 + 60 + 148.5
PC timing table(For RGB input)
Resolution
WXGA Panel Full HD Panel Horizontal Vertical
Nominal Pixel
Clock(MHz)
VGA VGA
Nominal Sync Nominal Sync
Frequency
(KHz)
Polarity Freq.(Hz) Polarity
640x480@60Hz ● ● 31.469 - 59.94 - 25.175
640x480@72Hz
● ● 37.861 - 72.809 - 31.5
640x480@75Hz
● ● 37.5 - 75 - 31.5
720x400@70Hz ● ● 31.469 - 70.087 + 28.322
800x600@56Hz
● ● 35.156 + 56.25 + 36
800x600@60Hz ● ● 37.879 + 60.317 + 40
800x600@72Hz
● ● 48.077 + 72.188 + 50
800x600@75Hz
● ● 46.875 + 75 + 49.5
1024x768@60Hz ● ● 48.363 - 60.004 - 65
1024x768@70Hz
● ● 56.476 - 70.069 - 75
1024x768@75Hz
● ● 60.023 + 75.029 + 78.75
1280x720@60Hz ● ● 45 + 60 + 74.25
1280x768@60Hz ● ●
47.396
/47.776
+
/-
59.995
/59.87
-
/+
68.25
/79.5
1280x1024@60Hz ● ● 63.981 + 60.02 + 108
1360x768@60Hz ● 47.71 + 59.799 + 85.5
1440x900@60Hz ●
55.935
/55.469
-
/+
59.887
/59.901
+
/-
106.5
/88.75
1680x1050@60Hz ●
64.674
/65.29
+
/-
59.883
/59.954
-
/+
119
/146.25
1920x1080@60Hz ● 66.587 + 59.934 - 138.5
