66
11. BOM List
Note: The following information of initial version BOM are only for reference of repair, not place the order as the
basis and are subject to change without notice. Please base on RSPL or Service BOM (http://cs.tpv.com.cn),
thank you!
LE32D1440/20 E32D9KNSCHB16NX
Location Part No. Description Remark
705TXDBCPD8 705 ASS’Y FOR BRAZIL PACKING
036T 600 18111 NONWOVEN FABRTC
036T 600 18119 GP NONWOVEN FABRTC
045G 77500 BARCODE RIBBON
045G 77501 BAR CODE RIBBON X300X75
092GB1JX1A3EGC BATTERY 1.5V LR03 AAA£¨LR03£© ALKALI
0M1G1030 6 47 CR3 SCREW
0M1G1030 8 47 CR3 SCREW
0M1G1730 6120 SCREW 3X6
0M1G1730 8120 SCREW
0Q1G 330 8 47 CR3 SCREW 3X8
0Q1G 940 10 47 CR3 SCREW 4X10
SP01 378G0110567YBE 8 OHM 11W 132X34 100 NO
E38901 389G224A12N0IS AC POWER CORD 1200 FOR BRAZIL 2nd Source
ECN601 395G801304DM88 HARNESS 4P-2P+2P 400/160MM
ECN701 395G801313FM87 HARNESS 13P-13P(2008) 230
ECN408 395G801830RM29 LVDS CABLE 30P TO 40P 500MM
ECN401 395G802210XM17 HARNESS 10P TO 5P+4P 900MM+500MM
398GRABD7NEACR REMOTE AOC RC2414704/01 ENGLISH 2nd Source
705TXDCK009 BASE SCREW ASS'Y
0M1G 940 8225 CR3 SCREW 4.0X8.0
Q45G 76 28NV2 R PE BAG FOR BASE SCREW SZ02742
X40G0001624 2A LABEL FOR SCREW PE BAG
705TXDCK012 STAND SCREW ASS'Y
0M1G1740 14225 CR3 SCREW
Q45T 76 28NV2 R PE BAG FOR BASE SCREW SZ02742
X40G0001624 2A LABEL FOR SCREW PE BAG
709G00XP000006 COMSUMPTIVE ASSY
052G 1185 MIDDLE TAPE (Y1200141)
Q45G 77 5 PE PACKING
052G 1185 MIDDLE TAPE (Y1200141)
052G 1185 MIDDLE TAPE (Y1200141)
Q45G66010TV01000X1 PROTECT BAG
E750 750TBV315X21H8N000 LCD PANEL TPT315B5-WX221 SC1H XM TPV XM 2nd Source
E750 LCB315WX221ADKE10X PANEL TPT315B5-WX221 SC1H XM TPV 2nd Source
P33T0486ADTW1L0100 COVER_KEY
P34T1239ADT02L0100 BASE
P34T14670GM04K0101 REAR_COVER
P34T1535ADT01L01BA DECO_BEZEL
PLTVDL121XXNK POWER BOARD
IC9102 056G 139 9 IC EL817M(X) PHOTOCOUPLER DIP-4
NR9902 061G 58159LAW 5A NTCR 1.5R 15% 2.4W SCK101R55LMY502
C9901 063G107K224 EM CAP X2 220NF 10% 305V BULK ( B )
L9902 073G 174241 X LINE FILTER 18MH MIN EF20 3LFEF2022-303M
L9901 073G 174241 X LINE FILTER 18MH MIN EF20 3LFEF2022-303M
L9102 073G 253 91 V CHOKE COIL 3.5UH+-10%
CN9901 087G 50147D HC AC SOKET R/A 2P 12DEGREE H=12.8
D8101 093G 60334 SCHOTTKY SR506-44 5A 60V DO-201AD
FOR
CN9901
0Q1G 340 8140 SCREW Q1-SELF TAPING SCREW :Q X8.0
