AOC Wipro WLA171t - Monitor Specifications; LCD Panel and Input Specs

17” LCD Color Monitor Wipro WLA171t
4
1. Monitor Specifications
Driving system TFT Color LCD
Size 43.2cm(17.0")
Pixel pitch 0.264mm( H ) × 0.264mm( V )
Viewable angle 160° (H) 160° (V)
LCD Panel
Response time 5 ms
Video R,G,B Analog Interface
Separate Sync. H/V TTL
H-Frequency 30kHz – 80kHz
Input
V-Frequency 50-75Hz
Display Colors 16.2M Colors
Dot Clock 135MHz
Max. Resolution 1280 × 1024 @75Hz
Plug & Play VESA DDC2B
TM
ON Mode ≤37W
EPA ENERGY STAR
®
OFF Mode ≤1W
Input Connector
15-pin D-Sub
Input Video Signal
Analog:0.7Vp-p(standard),
75 OHM, Positive
Maximum Screen Size
Horizontal : 338mm
Vertical : 270mm
Power Source 100~240VAC,47~63Hz
Environmental
Considerations
Operating Temp: 5° to 35°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 85%
Dimension 376(W)×382(H)×163(D)mm
Weight (N. W.) 4.2kg Unit (net)
Audio Output
Rated Power 1.5W rms
(Per channel)
Regulatory Compliance FCC, MPRII, cULus
