Replacement Air
Nozzles
2Ø
1325 Air Nozzle
1142 Air Nozzle
MODEL＃ NOZZLE SIZE Ø
1124 2.4mm
1130 4.4mm
1194 6mm
1195 8mm
1196 7mm
1197 9mm
1198 12mm
MODEL＃ IC SIZE L(mm)
1191 SIP25L 26
1192 SIP50L 52.5
MODEL＃ IC SIZE L(mm) W(mm)
1010 9×9mm 10 10
1313 12×12mm 13 13
1616 15×15mm 16 16
1919 18×18mm 19 19
2828N 27×27mm 28 28
3030N 29×29mm 30 30
3232W 31×31mm 32 32
3636W 36×36mm 36 36
3939W 38×38mm 39 39
4141W 40×40mm 41 41
4343W 42×42mm 43 43
4545W 44×44mm 45 45
MODEL＃ IC SIZE A(mm) B(mm) C(mm) D(mm)
1125 10×10mm 9 9 16 16
1126 14×14mm 14 14 21 21
1127 17.5×17.5mm 18 18 25 25
1128 14×20mm 20 14 21 27
1129 28×28mm 28 28 35 35
1215 42.5×42.5mm 41 41 48 48
1261 20×20mm 19 19 26 26
1262 12×12mm 11 11 18 18
1263 28×40mm 38 28 35 45
1264 40×40mm 39 39 46 46
1265 32×32mm 31 31 38 38
MODEL＃ IC SIZE
L(mm) W(mm) A(mm) B(mm)
1131 4.4×10mm 11 3.8 9 10.3
1132 5.6×13mm 16 4.7 14 11.7
1133 7.5×15mm 17 6 15 13
1134 7.5×18mm 20 6 18 13
1257 11×21mm 22 11 20 18
1258 7.6×12.7mm 12 7 10 14
1259 13×28mm 30 12.5 28 19.5
1260 8.6×18mm 20 7.7 18 14.7
MODEL＃ IC SIZE L(mm) W(mm) A(mm) B(mm)
1183 15×8mm 17 7 15 14
1184 18×8mm 20 9 18 16
1214 10×26mm 27 11 25 18
TSOL
SERIES
MODEL＃ IC SIZE
L(mm) W(mm) A(mm) B(mm)
1185 13×10mm 11 11 9 18
1186 18×10mm 12 17 10 24
1187 18.5×8mm 11 18 9 25
MODEL＃ IC SIZE
L(mm) W(mm) A(mm) B(mm)
1180 17×17mm 17.2 17.2 24.2 24.2
1181 19×19mm 18.2 18.2 25.2 25.2
1182 24×24mm 23.2 23.2 30.2 30.2
1203
35×35mm
34.2 34.2 41.2 41.2
BQFP
SE-
SGL SERIES
SIL SERIES
45º
10mm
5mm
22mm
22mm
22mm
22mm
22mm
22mm
22mm
SOJ
SERIES
SOP
SERIES
BGA
SERIES
QFP
SERIES
PLCC
SERIES
Ø
MODEL＃ IC SIZE A(mm) B(mm) C(mm) D(mm)
1135 17.5×17.5mm 17.5 17.5 24.5 24.5
1136 20×20mm 20 20 27 27
1137 25×25mm 25 25 32 32
1138 30×30mm 30 30 37 37
1139 7.3×12.5mm 7.5 12.5 14.5 19.5
1140 11.5×11.5mm 12 12 19 19
1141 11.5×14mm 12 14 19 21
1188 9×9mm 10 10 17 17
1189 34×34mm 35.5 35.5 42.5 42.5
