aoyue Int968 - Specifications

5
Power Input : available in 110V & 220V
Main Station Dimensions: 188(w) x 126(h) x 250(d) mm
Weight: 5.25Kg
SOLDERING IRON
Power Consumption: 35W
Temperature Range: 200°C - 480°C
Heating Element : Ceramic Heater
Output Voltage: 24V
Tip to Ground Resistance: Below 2 Ω
Tip to Ground Potential: Below 2mV
HOT AIR
Power Consumption: 550W
Temperature Range: 100°C - 480°C
Heating Element Ceramic / Metal Heating Core
Nozzle to Ground Resis- Below 2 Ω
Pump/Motor Type: Diaphragm Pump
Air Capacity: 23 l /min (max)
SMOKE ABSORBER
Vacuum Pressure: 600mm Hg
SPECIFICATION
