CD PLAYER
Compatible media Audio CD, CDR, CDRW, DVD, DVDR, DVDRW
Audio format Audio CD 16 bit PCM, MP3 32-320 kbps and variable bitrate,
WMA. ID3 tags are not supported.
USB - SD
Compatible media Flash memory sticks and cards, 32 Mb up to 32 GB.
File system recognized is FAT32. Some memory sticks and cards
may not work because they don’t allow direct memory access !
Audio format MP3 32-320 kbps and variable bitrate, WMA
ID3 tags are not supported.
CD-USB-SD
Line level output (balanced & unbalanced) 1.9V adjustable
Output impedance less than 1KΩ
Digital outputs (Toslink and Coax) SPDIF format, 16BIT, 44.1KHz
S/N ratio >90dB
THD <0.05%
Frequence range 20Hz - 20KHz
Power supply 230 VAC 50-60Hz max 30VA
Fuse rating 500mAT / 250V
Dimensions 430 (482) x 305 (315) x 44 mm
Net weight 4.5Kg
Shipping weight 5.5Kg
Accessories supplied Mains power cable, IR remote control unit
RS232 port Standard RS232 port on DB9 connector.
RS232 port setting (fixed) 38400 baudrate, 8 databits, no parity, handshake off
Infrared extension port Mini jack connector at the rear, disables the front infrared
receiver
Remote control battery type AAA type LR03
Operating temperature 10 - 40 °C
Relative humidity 10 to 80 % non condensing
Technical Specifications
