Installation and Quick Start 1
How to Avoid Equipment Damage
Disconnect
power for
Smart-UPS or
expansion
chassis
You do not need to turn off a Matrix-UPS
®
, Symmetra
®
UPS,
Silcon
®
UPS, or AIS 5000 UPS to install the Management
Card. For a Matrix-UPS, however, you must put the UPS in
maintenance bypass mode before you remove or install a
Management Card.
Smart-UPS
1. Turn off the
equipment that is
connected to the
UPS.
2. Disconnect the UPS
from its AC (input
power) source.
3. Press the OFF
button on the UPS
for approximately
five seconds to
turn off the DC
(battery) power.
Expansion chassis. Make sure that any Expansion Chassis or
Triple Expansion Chassis is disconnected from all power:
disconnect the chassis cable from the
UPS and, if the AC-to-DC
Adapter (AP9505) option is used, disconnect the adapter from
the chassis.
Damage to the UPS or Network Management Card
can result if you do not remove all AC and DC
power from a Smart-UPS
®
, an Expansion Chassis,
or a Triple Expansion Chassis before you install
the Management Card.
Te s t
