USER’S GUIDE
network management card
1
Introduction
Product Description
Features
The APC AP9617 Network Management Card EX is a web-based
management product that uses multiple, open standards such as Telnet,
HTTP, and SNMP to provide full management of supported devices:
The following is a list of some of this Management Card’s features:
Provides a Data Log accessible by FTP or a Web browser.
Provides an Event Log accessible by Telnet, FTP, or a Web browser
Detects connection speed of 10/100 MB per second.
Generates e-mail notifications for DC Power Plant events and
system events.
Limits SNMP traps and e-mail notifications based on the severity
level of the DC Power Plant or system events
For Magnum models, can be managed through InfraStruXure Manager.
Initial set-up
You must define three TCP/IP settings for the Network Management Card
before it can operate on the network.
IP address of the Management Card
Subnet mask
IP address of the default gateway
To configure the TCP/IP settings, see the Network Management Card
Quick-Start Manual (.\doc\en\Qckguide), provided in printed form, and in
PDF on the APC Network Management Card utility CD.

Other manuals for APC AP9617

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the APC AP9617 and is the answer not in the manual?

APC AP9617 Specifications

General IconGeneral
TypeNetwork Management Card
ModelAP9617
Data Link ProtocolEthernet, Fast Ethernet
Network Ports Qty1
Network ProtocolsTCP/IP, HTTP, HTTPS, SNMP, Telnet, SSH
ManagementSNMP
CompatibilitySmart-UPS
Remote Management ProtocolSNMP, HTTP, HTTPS, Telnet, SSH
SecuritySSL, SSH
Operating Temperature0 to 45 °C
Storage Temperature-15 to 65 °C
Humidity0 to 95% non-condensing
PortsRJ-45 Ethernet
