USER’S GUIDE
network management card
5
Front Panel
Introduction
The front-panel features of the Network Management Card (AP9617)
include Status LEDs, a Reset button, and a 10/100Base-T connector.
m
Features
10
Link - RX/TX Status
10/100Base-T
Reset
AP9617 Network Management Card EX
Smart Slot
/
100
Feature Description
Reset button Resets the Management Card while power remains on.
10/100 Base-T connector Connects the Management Card to the Ethernet network.
Link-RX/TX (
10/100) LED See Link-RX/TX (10/100) LED.
Status LEDs See Status LEDs.
