APC Network Management Card User Manual

Page 10 - 34003641EN/AF
1. Presentation
The Network Management Card is used to directly connect the UPS or STS to a computer network, while simultaneously
operating as a Web server and SNMP agent.
Remote connections are made using an ordinary internet browser or an NMS station.
All the functions offered by the Network Management Card are accessible via a number of APC by Schneider Electric
software applications, depending on the user’s needs.
Functions
Supervision
UPS or STS properties
UPS or STS log
System log
Alarm subscription
Direct email notification
Environement parameters
Configuration - Administration
Network parameters
Community name
Shutdown parameters (UPS only)
Scheduled shutdown (UPS only)
Management table
Time
Maintenance
Network cards discovery
Firmware upgrade
Reset agent
Factory reset
Servers/Workstations protection
Mupgrade or
Download
yes (Mupgrade)
yes
Web
browser
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
EPM
yes
yes
yes
yes
Console
Direct Telnet
yes yes
yes yes
yes yes
yes yes
yes yes
Network
Shutdown Module
(UPS only)
yes
yes
yes
yes
yes
yes
Supervision

APC Network Management Card Specifications

General

Device Type	Network Management Card
Data Link Protocol	Ethernet, Fast Ethernet
Management Protocols	SNMP, HTTP, HTTPS, Telnet, SSH
Remote Management Protocol	HTTP, HTTPS, SSH, Telnet, SNMP
Security	RADIUS, Secure Shell (SSH), Secure Sockets Layer (SSL)
Form Factor	Plug-in module
Features	Event logging
Power Requirements	Via UPS
Environmental Monitoring	Temperature, humidity (with optional sensors)
Network Interface	10/100 Mbps Ethernet
Compatibility	Compatible with select APC Smart-UPS and Symmetra UPS models
Firmware Updates	Yes, via network or web interface
