CHAPTER 1: OVERVIEW
2
Navigation Keys Name Sound Function
? Help Short beep Opens context-sensitive help.
Enter Short beep Opens the selected menu item or setting.
Two short
beeps
When pressed simultaneously for about one second,
resets the PowerView RM interface.
ESC + ? +
Escape + Help
+ Enter
One long beep When pressed simultaneously for about three
seconds, puts the interface in programming mode for
installing new language program files.
Navigation
The normal display on the PowerView is the monitoring screen shown below. A snapshot of the UPS status is
provided. Pressing ‘Esc’ multiple times will always allow return to this display.
Chrg 100%........
Load 20%.......
206Vin 208Vout 60Hz
Runtime: 0hr 27min
From the monitoring screen, press ‘Esc’ to get to the Main Menu.
Control Logging
Status Display
>Setup Diags
Accessories Help
The Main Menu provides access to each of the different function groups provided below. Use the navigation keys
to select the desired group. Chapter 3: Menu Commands in this manual provides detailed descriptions of each
functional group and its associated commands.
Menu Description
Control Provides power control commands, such as Load ON and Load OFF.
Status Displays information regarding load, battery and power modules, voltage, and electrical
current.
Setup Allows the user to customize the UPS functionality.
Accessories Allows monitoring of installed APC accessories, if these are present.
Logging Provides ability to log system events.
Display Allows configuration of PowerView display settings.
Diagnostics Provides detailed information useful in troubleshooting the system.
Help Provides access to help information.

APC Symmetra LX Specifications

General

Form factor	1U
Certification	CSA, UL 1778
Product color	Silver
Battery voltage	120 V
Battery capacity	864000 mAh
Battery technology	Sealed Lead Acid (VRLA)
Dimensions (WxDxH)	210 x 546 x 140 mm
Battery life	3 year(s)
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-15 - 45 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	85079080

Weight and Dimensions

Weight	29100 g
Package weight	32280 g
