APC Symmetra LX User Manual

CHAPTER 2: BASIC COMMANDS
4
Set the Correct Output Voltage
1. Press the ‘Esc’ button until the Main Menu appears. Use the up and down arrow keys to choose ‘Setup’, and
ENTER to select.
Control Logging
Status Display
>Setup Diags
Accessories Help
2. Use the arrow keys and ENTER to select ‘Other’.
Settings: Alarms
Shutdown Bypass
Defaults Copy
Output Freq >Other
3. If the output voltage is not correct for your application, use the arrow keys, and ENTER to select ‘Output’. The
cursor will move to the voltage field, as the up and down arrows scroll through available choices. Choose the
desired voltage setting and press ENTER to select.
Self Test: Enabled
UPS ID: UPS_IDEN
Vout Reporting: AUTO
>Output: 208V
Supply Power to the Load Equipment
The Symmetra LX must be turned on before executing this procedure.
1. Press ‘Esc’ until the Main Menu appears. Use the arrow keys to choose ‘Control’ and ENTER to select.
>Control Logging
Status Display
Setup Diags
Accessories Help
2. Use the arrow keys to choose ‘Turn UPS Output On’ and ENTER to select. NOTE: You must scroll to a
second page of choices.
Graceful Turn Off
Start Runtime Cal
>Turn UPS Output On
3. Confirm choice by selecting ‘YES’.
Confirm:
Turn UPS On
CANCEL
>YES, Turn UPS On
4. There will be clicking sounds and this message will appear. NOTE: You may be given one or more override
warnings. Answer these by selecting ‘Start Now’.
UPS HAS BEEN COMMANDED
TO TURN LOAD POWER ON

APC Symmetra LX Specifications

General

Form factor	1U
Certification	CSA, UL 1778
Product color	Silver
Battery voltage	120 V
Battery capacity	864000 mAh
Battery technology	Sealed Lead Acid (VRLA)
Dimensions (WxDxH)	210 x 546 x 140 mm
Battery life	3 year(s)
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-15 - 45 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	85079080

Weight and Dimensions

Weight	29100 g
Package weight	32280 g
