Punch Factory
Page 12
Punch Factory
Input Z
10MegΩ
Output Z
Instrument: 1KΩ
D.I.: 150Ω
Maximum Input Level 1.5V RMS
Frequency Respomse 10Hz - 30kHz +/- 1dB
SNR (Typical) 70dB
Compression Ratio Variable: Approx 1.5:1 to 10:1
Maximum Gain 30dB
Max Compression Range >30dB
Power Drain 5mA
Battery Type 9V (Alkaline recommended)
External Power
Must be CE certified
5-32VAC
7-48 VDC
+48V Phantom
Specifications
Aphex reserves the right to continually improve our prod-
ucts. All specifications are subject to change without
notice.
