Punch Factory
Page 4
Input
Connect your instrument here. The power is automatically
switched on or off by inserting or removing the plug from the
input jack. Only removing the plug from your instrument does
not turn off the Aphex unit.
Output
Connect this output to your amp’s input jack using a good qual-
ity guitar cable. Use the same settings on your amplifier as you
would use if plugging the instrument directly into the amp to get
normal volume and tone when you switch the effect off, and your
instrument passes directly through the pedal to your amp’s input.
D.I. Output
This pedal comes with a high quality balanced D.I. output. Pin 2
of the XLR is hot while pin 3 carries a balancing impedance to set
up a true balanced line. Pin 1 is grounded through the ground-
lift switch. The D.I. output can be connected to the microphone
input of any preamp or sound mixer and runs a level of typically
-50 to -60 dBu depending on your instrument’s volume setting.
The D.I. output should normally be grounded. Don’t lift the
ground unless it actually eliminates hum or buzz.
