API FILSTAR XP - Filter Parts and Accessories; Customizing Filter Media Configuration; Main Filter Components; Filter Accessory Items

DIRECTIONS
3
MIX YOUR MEDIA AS YOU WISH
XP-L
XP-S
XP-M XP-XL
MICRO-FILTRATION or
PROGESSIVE MICRO-FILTRATION
BIO-CHEM ZORB 
 
  
REMOVER according to the needs of
your aquarium.
BIO-CHEM STARS®
XP-S: 8 -10 stars
XP-M: 15 - 20 stars
XP-L: 30 - 35 stars
XP-XL: 50 - 55 stars
FOAM 30 PPI
FOAM 20 PPI
A
B
C
D
E
PARTS
1. FILSTAR XP FILTER
2. Quick disconnnect valve
3. API® BIO-CHEM ZORB®
4. API® BIO-CHEM STARS® (5 each)
5. Flexible tubing (2 each)
6. Accessories:
A. Goose neck
B. Outlet pipe
C. Inlet pipe
D. Inlet pipe cap
E. Inlet pipe 3” (8 cm) extension (2 each)
F. Inlet strainer
G. Suction cups (4 each)
H. Suction cup clamps (4 each)
I. Flexible tubing clamps (4 each)
2
4
3
5
1
B
D
C
E
F
A
G
H
I
